• 测试电流可达AC2000A.
• 峰值保持功能.
• 直径55mm大口径水滴形钳口.
AC A | 400A (0 - 400A) |
±1.5%rdg±3dgt [45 - 65Hz] | |
±2.5%rdg±3dgt [40Hz - 1kHz] | |
2000A (0 - 1500A) | |
±2%rdg±5dgt [45 - 65Hz] | |
±3%rdg±5dgt [40Hz - 1kHz] | |
2000A (1501 - 2000A) | |
±4%rdg [50/60Hz] | |
AC V | 40/400/750V |
±1%rdg±2dgt [45 - 65Hz] | |
±1.5%rdg±3dgt [40Hz - 1kHz] | |
DC V | 40/400/1000V ±1%rdg±2dgt |
Ω | 400Ω/4k/40k/400kΩ ±1.5%rdg±2dgt |
导通蜂鸣 | 50±35Ω以下时蜂鸣 |
导体直径 | Ø55mm. |
频率反应 | 40Hz - 1kHz |
输出 | 记录仪 : |
DC400mV against AC400A | |
DC200mV against AC2000A | |
安全规格 | IEC 61010-1 CAT III 600V , CAT II 1000V |
IEC 61010-2-031 | |
IEC 61010-2-032 | |
电池 | R6 (AA) (1.5V) × 2 |
尺寸 | 247(L) × 105(W) × 49(D)mm |
重量 | 约 470g. |
附件 | 7107A (测试线) |
9094 (便携箱) | |
R6 (AA) × 2 | |
使用说明书 | |
可选件 | 7256 (测试线) |
