• 直流电压量程极适用于检查紧急电池动作的电源供应器.
• 夹钳设计成水滴状，方便使用.
AC A | 6/15/60/150/300A 刻度值的±3% |
AC V | 150/300/600V 刻度值的±3% |
DC V | 60V 刻度值的±3% |
Ω | 1/10kΩ (中间值 25/250Ω ) |
刻度的±2% | |
Temperature | Note: The MODEL2608A includes a temperature measurement scale, |
but it is not available for new customers due to the discontinue of the Temperature Probe 7060. | |
Conductor size | Ø33mm max. |
Frequency response | 50Hz/60Hz |
Applicable standards | IEC 61010-1 CAT III 300V Pollution Degree 2 |
IEC 61010-2-031 | |
IEC 61010-2-032 | |
Power source | R6 (AA) (1.5V) × 1 |
Dimensions | 193(L) × 78(W) × 39(D)mm |
Weight | 275g approx. |
Included Accessories | 7066A (Test leads) |
8923 (Fuse [0.5A/600V]) × 2 | |
9097 (Carrying case) | |
R6 (AA) × 1 | |
Instruction Manual |
