德国IBP HDC75血液透析机质量分析仪除了可以测量血透机的电导率、温度、压力、pH值和流速这5个计量规程要求的测试值。
德国IBP HDC75血液透析机质量分析仪应用范围：
德国IBP HDC75血液透析机质量分析仪Win10操作系统的专用手持机，除了可以测量血透机的电导率、温度、压力、pH值和流速这5个计量规程要求的测试值以外，HDC75还拥有强大的软件功能，可以实时观察各个数值的波形变化曲线，还可以保存和管理多个血透机的检测结果,数据无需再传到电脑。
德国IBP HDC75血液透析机质量分析仪商品详情：
HDC75血液透析机质量分析仪,德国IBP HDC75血液透析机质量分析仪标准配置
HDC75主机 1个,电导度探测器1个、温度多功能探头 1个,压力传感器1个,流量传感器1个,pH探头1个,连接线1套,电导率校准液 1瓶,充电器1个,便携箱 1个
Application includes | |
| |
Pressure | |
| Hemodialysis machines |
| Ophtamological lasers |
| Blood pressure meters |
| Automatic tourniquets |
| Drainage devices |
| IV pumps |
| Diagnostic, surgical suction |
| Ventilators |
| Pressure gauges |
| RO-Water Systems |
Temperature | |
| Hemodialysis machines |
| Temperature monitors |
| Electronic thermometers |
| Humidifiers/nebulizers |
| Blood warmers |
| Hypo/hyperthermia machines |
| Infant incubator |
| Radiant warmers |
Conductivity | |
| Hemodialysis machines |
| RO-Systems |
| Water Treatment |
Flow | |
| Hemodialysis machines |
| RO-Water Systems |
| Water Treatment |
New Concept
The Biomed-Lab system is a new approach to combine a family of intelligent reference sensors, sources and vital signs simulators with a handheld smart computer for testing and quality control of medical instrumentation. The product line combines more than 30 years of experience of innovative measuring device development.
Customisable
The modular concept of the Biomed-Lab system allows the use of any combination of sensors in order to fulfill user specific test or calibration requirements. Only one central unit for all the daily tasks needed.
HDC75 Display and Control Unit | ||
| ||
| 7" Touch Screen | |
| 5 Sensor ports | |
| Windows 10 based | |
| AC and battery operation | |
| 14000 mAh battery | |
| Robust housing | |
Advanced Hard- and Software
Advanced electronics technology combined with highly developed software results in a completely new type of measuring system with features and a high level of accuracy simply not achievable with other units.
The central unit is based on Microsoft Windows 10. This allows to use all the features of a modern smart computer. Data handling was never so easy.
For different applications different software is available. The basic Biometer-Software allows to read measuring values both in numerical and grafical way.
Quality
The HDU-Sensors are developed and produced under certified quality management system according to 13485. We offer an annual sensor calibration service with certification in accordance with the ISO 17025 standard.
德国IBP HDC75血液透析机质量分析仪技术参数：
1. 压力：
范围：-650 至+1550mmHg,分辨率：0.01mmHg,精度：满值的0.05%
2. 电导率
范围： 0到200.00 mS/cm,
分辨率：
0到199uS/cm 0.3% ±0.6uS/cm,
200 到1999uS/cm ±0.6uS/cm,
2到 11.99mS/cm ±0.06mS/cm,
12到 19.99mS/cm ± 0.03mS/cm,
20到200mS/cm±0.6mS/cm
3. 温度
范围：0到100°C,分辨率：0.01°C,精度：±0.05°C(25 - 40°C)
4. pH值
范围：0到14pH,分辨率：0.01pH,精度： 0.02pH
5. 流速
范围：100到2000ml/min,分辨率：1ml/min,精度： 1%
